17-seat lithium-ion electric sightseeing car

After purchasing an Electric Sightseeing Car, maintenance should be carried out to check whether the contact points of the vehicle power circuit are loose. We should regularly maintain the Electric Vehicle to prevent the contact points from being damaged and overheated due to poor contact, and to prevent short circuits and series current safety accidents caused by aging and damage of the line. The main wiring harness of Electric Customized Vehicles is different from the auxiliary vehicle wiring harness, and a new battery line connection method is used, which maintains safety fire protection and eliminates safety risks from small details.







17 seats, motor controller (lithium battery, matching 30KW motor), motor (permanent magnet synchronous motor assembly 144V30KW), electric column and controller assembly (electric power steering), vacuum booster and brake master cylinder assembly, steel wheels (tire 195/70R15C), wheel hub cover, front independent plastic seats (2) + middle independent plastic seats (3 rows * 3) + rear independent plastic seats (3) + back-to-back independent plastic seats (3), seat belts, floor leather, stretch mesh rain curtain, radio + USB interface + speakers (2), DCDC charger two-in-one assembly 1.5KW + 6.6KW, lithium battery (147.2V/230Ah, with heating), fire extinguisher bracket, on-board tools, driver cup holder, top interior.
